ASUS TUF Gaming Radeon™ RX 9070 OC Edition 16GB GDDR6 256-bit Graphics Card
SPECIFICATION
|
Model |
TUF-RX9070-O16G-GAMING |
|
Graphic Engine |
AMD Radeon™ RX 9070 |
|
Bus Standard |
PCI Express 5.0 |
|
OpenGL |
OpenGL® 4.6 |
|
Video Memory |
16GB GDDR6 |
|
Engine Clock (OC Mode) |
Up to 2670 MHz (Boost) / Up to 2190 MHz (Game) |
|
Engine Clock (Default Mode) |
Up to 2650 MHz (Boost) / Up to 2170 MHz (Game) |
|
Stream Processors |
3584 |
|
Memory Speed |
20 Gbps |
|
Memory Interface |
256-bit |
|
Digital Max Resolution |
7680 x 4320 |
|
Display Outputs |
1 x HDMI 2.1b, 3 x DisplayPort 2.1a |
|
HDCP Support |
Yes (2.3) |
|
Maximum Display Support |
4 displays |
|
NVLink/Crossfire Support |
No |
|
Accessories |
TUF Certificate of Reliability, TUF Gaming Graphics Card Holder, TUF Velcro Hook & Loop, TUF Fridge Magnet, Thank You card, Speedsetup Manual |
|
Software |
ASUS GPU Tweak III & Drivers (download from the support site) |
|
Dimensions |
330 x 140 x 62.5 mm (13 x 5.5 x 2.5 inches) |
|
Recommended PSU |
750W |
|
Power Connectors |
2 x 8-pin |
|
Slot Width |
3.125 Slots |
|
AURA SYNC (RGB) |
Yes |
|
Notes |
Wattage recommendation is based on a fully overclocked GPU/CPU system. Specifications subject to change. Game Clock is typical for gaming applications; Boost Clock is burst frequency. |
