AOC 23.8" 24B36XE/71 IPS Monitor - Black

Model Name

24B36XE

Panel

23.8" / IPS

Pixel Pitch (mm)

0.2745 (H) × 0.2745 (V)

Effective Viewing Area (mm)

527.04 (H) × 296.46 (V)

Brightness (typical)

300 cd/m²

Contrast Ratio

1500 : 1 (typical) / MEGA DCR

Response Time

4ms GtG / 0.5ms MPRT

Viewing Angle

178° (H) / 178° (V) (CR > 10)

Color Gamut

NTSC 90% (CIE1976) / sRGB 101% (CIE1931)

Optimum Resolution

1920 × 1080 @ 144Hz – HDMI
1920 × 1080 @ 75Hz – VGA

Display Colors

16.7 Million

Signal Input

VGA × 1, HDMI 1.4 × 1

USB Hub

No

Power Supply

External 19VDC, 1.31A

Power Consumption (typical)

18W

Speakers

No

Line In/Earphone

Yes

Wall-Mount

100 mm × 100 mm

Adjustable Stand

Tilt: -5° ~ 23°

Product without Stand (mm)

318.5 (H) × 544.0 (W) × 34.7 (D)

Product with Stand (mm)

413.8 (H) × 544.0 (W) × 198.0 (D)

Packaging (mm)

420 (H) × 615 (W) × 112 (D)

Product without Stand (kg)

2.21

Product with Stand (kg)

2.50

Product with Packaging (kg)

3.69

Cabinet Color

Black

Regulatory Approvals

CE / FCC / RoHS
