MERCUSYS HALO H30G (3-Pack) AC1300 Whole Mesh Wi-Fi System

Wireless Standards

IEEE 802.11 a/n/ac 5 GHz, IEEE 802.11 b/g/n 2.4 GHz

WiFi Speeds

867 Mbps on 5 GHz, 400 Mbps on 2.4 GHz

Reception Sensitivity

2.4 GHz:

- 11g 6Mbps: -96dBm

- 11g 54Mbps: -78dBm

- 11n HT20 MCS7: -76dBm

- 11n HT40 MCS7: -73dBm

5 GHz:

- 11a 6Mbps: -95dBm

- 11a 54Mbps: -77dBm

- 11ac VHT20 MCS8: -72dBm

- 11ac VHT40 MCS9: -67dBm

- 11ac VHT80 MCS9: -63dBm

Transmission Power

2.4 GHz < 20dBm (EIRP)

5 GHz < 23dBm (EIRP)

Wireless Security

WPA-PSK/WPA2-PSK

Mesh Protocol

802.11k/v/r

Software Features

Operation Modes

Router, Access Point

Quality of Service

WMM

WAN Type

Dynamic IP/Static IP/PPPoE/L2TP/PPTP

Management

Local Management, Remote Management, Multi-Managers

DHCP

Server, Client

Firewall Security

SPI Firewall

Protocols

Supports IPv4 and IPv6

Guest Network

2.4 GHz Guest Network x 1, 5 GHz Guest Network x 1

Hardware Specifications

Dimensions

3.5 × 3.5 × 3.5 in (88 × 88 × 88 mm)

Interfaces

2× Gigabit Ports per Halo Unit (WAN/LAN auto-sensing)

Button

Reset button

Other Information

Package Contents

3× Halo H30G Units, 1× RJ45 Ethernet Cable, 3× Power Adapters, 1× Quick Installation Guide

Environment

Operating Temperature: 0°C104°F)

Operating Humidity: 10%~90% Non-Condensing

Storage Humidity: 5%~90% Non-Condensing
